Benefits to the unique design of AIRTEC’s valves for ATEX and FM/CSA directives include:
• “AIRTEC-Ring” sealing system
• Virtually zero leak/bubble tight
• Pressure range from full vacuum (29.5 Hg) to 145 psi
• Solid aluminum body
• Contamination resistant
• Heat resistant
• Continuous duty coils
Available configurations as pneumatically operated valves, single & double solenoid valves, spring centered 3-position valves, valves with external pilot supply, manual valves, NAMUR valves, manifolds & sub-bases, ATEX or FM/CSA explosion proof, and custom solutions.
Technical data
Sizes: Nominal Flow Rates
M5: 38, 220 NI/min (.039, .224 Cv)
1/8: 56, 360, 750, 950, N1/min. (1.606, 2.134 Cv)
1/4: 1580, 2100 N1/min. (1.606, 2.134 Cv)
1/2: 3300 N1/min (3.354 Cv)
